Types of Container Gantry Crane
AICRANE offers three distinct types of container gantry cranes: Railway Gantry Crane, Rail Mounted Container Gantry Crane, and Rubber-Tired Container Gantry Crane. Each type is designed with specific features to cater to various operational environments and container handling demands.
Railway Gantry Crane
RMG Container Gantry Crane
RTG Container Gantry Crane
Railway Gantry Crane
It is an ideal solution for managing the transfer of containers between rail cars and storage areas, provides stable, precise container handling on fixed rails at railway yards.
- Lifting capacity: 30t, 35t, 40.5t, 45t, 50t, customized
- Span: 18~35m
- Lifting height: 12.3~21m
- Lifting speed: 9~12.5m/min
- Work duty: A6-A8
Get Quote
RMG Container Gantry Crane
Perfect for ports and large container yards, operates on fixed rails with the customizable cantilevers. These cantilevers can cover wider spans and work over adjacent stacks or rail tracks.
- Lifting capacity: 30t, 35t, 40.5t, 45t, 50t, customized
- Span: 18~35m
- Lifting height: 12.3~21m
- Lifting speed: 9~12.5m/min
- Work duty: A6-A8
Get Quote
RTG Container Gantry Crane
A flexible solution for areas lacking rail infrastructure, the rubber-tired container gantry crane offers mobility for efficient container handling in dynamic, space-constrained environments.
- Lifting capacity: 30t, 35t, 40.5t, 45t, 50t, customized
- Span: 18~35m
- Lifting height: 12.3~21m
- Lifting speed: 9~12.5m/min
- Work duty: A6-A8
Get Quote
Applications of Container Gantry Crane
Container gantry cranes are widely used in logistics and transportation industries such as ports, railway freight yards, and large container depots. They are suitable for the efficient loading, unloading, handling, and stacking of containers, enhancing logistics and cargo transfer efficiency.
For large container depots
Used in railway freight yard
For port
Video of Container Gantry Crane
Choose the Right Container Gantry Crane
- 1. how many containers do you need to lift per time；
- 2. how about the max lifting capacity do you need；
- 3. span (width between the two legs)；
- 4. height ( distance the goods are lifted from the ground)；
| Technical Parameter of container Gantry Crane | ||||||
| Capacity | t | 30 | 35 | 40.5 | 45 | 50 |
| Span | S(m) | 18~35 | 18~35 | 18~35 | 18~35 | 18~35 |
| Lifting height | m | 12.3~21 | 12.3~21 | 12.3~21 | 12.3~21 | 12.3~21 |
| Lifting speed | m/min | 12.5 | 9.5 | 10 | 9.8 | 9.2 |
| Trolley speed | m/min | 56 | 48 | 48 | 45 | 45 |
| Crane speed | m/min | 50 | 44.3 | 44.3 | 42 | 42 |
| Container | 20′ 40′ | 20′ 40′ 45′ | 20′ 40′ 45′ | 20′ 40′ 45′ | 20′ 40′ 45′ | |
| Work duty | A6~A8 | A6~A8 | A6~A8 | A6~A8 | A6~A8 | |
| Track type | QU80 | QU80 QU100 | QU80 QU100 | QU100 QU120 | QU100 QU120 | |
Cases of Container Gantry Crane
Location: Almaty, Kazakhstan
Type: Rail Mounted Container gantry crane
Parameters: Capacity 45t, span 38m, height 15m
Each effective cantilever: 7m + 9m
Installation method:
On-site installation and commissioning assistance
Application:
For lifting 20ft, 40ft, and 45ft containers at logistics stations.
Installation time: February, 2024
Location: Ukhta
Type: MG Rail Mounted Container gantry crane
Parameters: Capacity 40t, span 32m
Installation method:
On-site installation and commissioning.
Application:
For lifting containers in the clients’freight yard.
Installation time: May, 2023
Location: Atyrau, Kazakhstan
Type: MGH European standard double girder gantry crane
Parameters: Capacity 32t, span 30m, height 13m
Installation method:
Online installation guidance and on-site commissioning assistance
Application:
For lifting containers at the logistics station in Atyrau.
Professional Service Team in Aicrane
Aicrane® professional service team is composed of highly skilled and experienced technicians who have undergone rigorous training and certification in the installation, maintenance, repair, and troubleshooting of the company’s equipment. Our service team will provide you customized solutions that meet your lifting needs according to actual working conditions.
FAQs
- We usually use plastic film and standard export fumigation-free wooden box to prevent the damage by rain;
- We also reinforce it with iron nails or steel plates to avoid damage during transportation.
- If you purchase Aicrane container gantry cranes, we will provide installation and maintenance instruction manuals to help;
- If you have any questions during the installation process, we have professional technical engineers to guide the installation online;
- If you have special needs for on-site guidance, we can send engineers to your site as appropriate.
- We recommend a comprehensive maintenance and inspection of the RTG every 3 months;
- Maintenance should include cleaning, lubrication, tightening bolts and checking the electrical system.
- We provide one-stop service, from delivery, installation to after-sales with professional team;
- We also provide online customer service ready to solve your problems at any time, and after-sales documentation support;
- If the problem still not be solved, we can send our engineers to your site.
