Rubber Tyred
GantryCrane

  • Capacity 10-800T, support customization
  • Higher flexibility and mobility for operation
  • Suitable for various fields, such as construction sites, storage yards, ports, etc.

Applications

RTG crane have high flexibility and versatility, and are often used in different work conditions for loading and unloading materials and moving heavy objects, such as on construction sites, port terminals, tunnel and bridge construction, logistics storage, etc.

For Storage Yards
For Bridge Construction
For Factories and Workshops
For Construction Sites
For Container Terminals

Different Types of Rubber Tyred Gantry Crane

rubber-tyred-gantry-crane-T1
RTG Crane Single Girder

Lifting capacity:10-80 ton

Span:18-35 m

Lifting height:6-18 m

Features: High mobility, ideal for use in tight spaces or areas with limited maneuverability.

rubber-tyred-gantry-crane-T2
RTG Crane Double Girder

Lifting capacity:20-800 ton

Span:18-35 m

Lifting height:6-18 m

Features: Mainly used for stacking containers in a railway station, port; Available for ISO standard containers.

rubber-tyred-gantry-crane-T3
RTG Crane A-Frame

Lifting capacity:10-800 ton

Span:18-35 m

Lifting height:6-18 m

Features: Widely used in an open warehouse, material stocks, cement plant, granite industry to lift, load, and unload goods, etc.

rubber-tyred-gantry-crane-T4
Straddle Carrier Gantry Crane

Lifting capacity:10-800 ton

Span:18-35 m

Lifting height:6-18 m

Features: Lift, move, load, unload, erect heavy loads, such as precast concrete beams, long pipes, wall, handling plates, etc.

RTG Cranes Available in Electric and Hydraulic Drive Modes
Costomize Solutions for Your Needs!
Contact Us

Operation Video of Rubber Tyred Gantry Crane

This video clearly demonstrates the structure of rubber tyred gantry crane and its flexibility. It can realize the function of straight movement, 90-degree lateral movement, oblique movement, pivot steering, Ackerman steering, forward swing and retral swing.

Straight movement

Forward swing

Retral swing

Selection of spreaders for Rubber Tyred Gantry Crane

Spreader is the key component of RTG cranes, and the selection of the spreader is determined by the actual working conditions. We provide various types of spreaders, such as steel coil spreader, beam spreader, hook, etc., to meet the needs of various lifting materials. In addition, we will also help you customize suitable container spreaders according to your requirements.

hook-spreader-04
Hook spreader

steel-coil-spreader-01
Steel coil spreader

lifting-beam-03
Beam spreader

customized-spreader-06
Customized spreader

container-spreader-05
Container spreader

lifting-clamp-02
Segment spreader

Solutions of Rubber Tyred Gantry Crane

Aicrane is a professional crane equipment manufacturer. We have customized various types of rubber-tyred gantry solutions for customers from different countries,in order to meet their specific lifting needs. The following is a display of some schemes:

<
01

/04

YTL Double Girder Rubber Tyred Gantry Crane

Lifting capacity: 15T
Application: Stacking containers in Logitsic Hub

02

/04

DTL Single Girder Rubber Tyred Gantry Crane

Lifting capacity: 10T
Application: Lifting and moving materials in the warehouse

03

/04

A-Frame Double Girder Rubber Tyred Gantry Crane

Lifting capacity: 50+50T
Application: Loading and unloading of heavy steel in steel plants

04

/04

Double Girder Rubber Tyred Gantry Crane

Lifting capacity: 45T
Application: Handling concrete plates in bridge construction

>

Cases of RTG Crane

rtg crane-case-Nicaragua
Rubber Tyre Gantry Crane Delivered to Nicaragua

Delivery Time: August, 2023

Location: Nicaragua

Type: DTL double girder rubber tyred gantry crane

Parameters: capacity 60 tons

Application:

For railway construction.

Learn More
rubber tyred gantry crane in uae
Operational Testing of 10T Rubber Tyred Gantry Crane in UAE

Installation time: February, 2023

Location: UAE

Type: DTL single girder rubber tyred gantry crane

Parameters: Capacity 10t, span 9.1m, height 6+18m

Installation method:

Online installation guidance

Application:

For indoor maintenance of valves in the Barakah Nuclear Power Plant.

Learn more
rtg crane-case-argentina
Operation of Rubber Tyred Gantry Crane in Argentina

Installation Time: July, 2022

Location: Argentina

Type: DTL double girder rubber tyred gantry crane

Parameters: capacity 12.5 tons

Application:

For Handling steel plates in construction site.

Learn More

Professional Service Team in Aicrane

Aicrane professional service team is composed of highly skilled and experienced technicians who have undergone rigorous training and certification in the installation, maintenance, repair, and troubleshooting of the company’s equipment. Our service team will provide you with Rubber Tyred Gantry Crane solutions that meet your lifting needs according to your actual working conditions or project scenarios.

24/7 online customer service is available to answer your calls efficiently.

Professional techs are dedicated to customizing solutions tailored to you.

Reliable service in the production, consignment, and installation process.

Perfect after-sales service ensures your long-term satisfaction.

FAQs

How can I choose a right RTG cranes?
We have 24-hour online customer service to provide you with professional consulting services and help you choose the right RTG cranes according to your working conditions. Of course, the more usage information you provide, the more accurate our options will be. The following is the product information for reference:
  • how about the max lifting capacity do you need;
  • span (width between the two legs);
  • height ( distance the goods are lifted from the ground);
  • what kind of materials you need to lift.

How can you package and ship RTG cranes?
Our product packaging is usually packed with plastic film and standard export fumigation-free wooden box or plywood box to prevent the product from being damaged by rain. We also reinforce it with iron nails or steel plates to avoid damage during transportation.

How can I install an RTG cranes?
If you purchase Aicrane rubber tyred gantry cranes, we will provide free installation and maintenance instruction manuals to help; if you have any questions during the installation process, please feel free to consult us, we have professional technical engineers to guide the installation online. If you have special needs for on-site guidance, we can send engineers to your site as appropriate.

How long do RTG cranes need to be maintained?
RTG cranes require regular maintenance and inspections to ensure they are always running at their best. Under normal circumstances, we recommend a comprehensive maintenance and inspection of the RTG every 3 months, which includes cleaning, lubrication, tightening bolts and checking the electrical system.

How can you provide after-sale service?
This is a common concern for customers. We provide one-stop service, from delivery, installation to after-sales. We will have online customer service ready to solve your problems at any time, we also provide after-sales documentation support, such as operation manuals, maintenance manuals, etc. If the problem still not be solved, we can send our engineers to your site.

    Contact Us Now!

    Please specify your requirement by referring to the following aspects:

    • Lifting capacity (ton)?

    • Lifting height (m)?

    • Span length (m)?

    • What to lift?

    • If you have any special requirements or needs, please explain them here so that we can serve you better!
